THE Type-MMB is a micro-miniature capacitor, composed
of ultra-thin metallized polyester film made available by our
unique engineering method to meet the needs of miniaturization.
FEATURES:
■ 5.0mm(.200") lead spacing on all values.
■ Non-inductive construction.
■ Self-healing property.
■ Space-saving miniature size.
■ High moisture resistance , Good solder ability.
■ Available on tape and reel for automatic insertion.

APPLICATIONS:
They are ideal for blocking , coupling , decoupling , filtering , by-pass ,
timing circuits and other general purpose usage.

SPECIFICATION:
1.Operating temperature : -55℃ ～ +105℃ (+85℃ ～ +105℃ : decreasing factor 1.25% per ℃ for RV )
2.Capacitance range : .001μF ～ 1.5μF
3.Capacitance tolerance : J=±5% , K=±10% , M=±20%
4.Rated voltage (RV) : 50V/63V , 100 , 250 , 400VDC
5.Dissipation factor (DF) : 1.0% max (at 1KHz 25℃)
6.Testing voltage (TV) : 160% of RV for 60sec.
7.Insulation resistance (IR) : C≦.33μF and RV≦100vdc ,≧15,000MΩ (at 25℃)
(Measured at RV or 500Vdc C＞.33μF and RV≦100vdc ,≧ 5,000MΩ.μF
whichever is smaller , charge C≦.33μF and RV＞100vdc ,≧30,000MΩ
time 60s) C＞.33μF and RV＞100vdc ,≧10,000MΩ.μF
