| Type-MPT |
|
|
 THE Type-MPT are constructed with metalized polypropylene film
dielectric , tin copper wire leads , outer wrapped with polyester film tape and ends sealed with epoxy resin , in non-inductive type.
FEATURES:
■ Indicate tubular and axial lead.
■ Self-healing property , Low DF, High IR.
■ High frequency and high current circuits applications.
■ High stability of capacitance and DF versus temperature and frequency.
■ Available on tape and reel for automatic insertion.
APPLICATIONS:
They are ideal for telecommunication equipment's , data processing equipment's , industrial instruments , automatic control systems and other general electronic equipment's.
SPECIFICATION:
1.Operating temperature : -40℃ ∼ +85℃
2.Capacitance range : .01μF ∼ 10.0μF
3.Capacitance tolerance : J=±5% , K=±10% , M=±20%
4.Rated voltage (RV) : 160 , 250 , 400 , 630VDC
5.Dissipation factor (DF) : 0.1% max (at 1KHz 25℃)
6.Testing voltage (TV) : 160% of RV for 60sec.
7.Insulation resistance (IR) : C≦.33μF,≧100,000MΩ , C＞.33μF,≧33,000MΩ.μF (at 25℃)
(Measured at RV or 500Vdc whichever is smaller , charge time 60s)
 |
