| Type-MPP |
|
|
 THE Type-MPP are constructed with metalized polypropylene film dielectric ,tinned copper wire leads and epoxy resin coating , in non-inductive type .
FEATURES:
■ Self-healing property , Low DF, High IR.
■ High frequency and high current circuits applications.
■ High stability of capacitance and DF versus temperature and frequency.
■ Flame retardant epoxy resin coating (UL-class 94V-0).
APPLICATIONS:
They are ideal for blocking , by-pass , coupling , decoupling filtering ,timing tuning ,temperature compensation and TV or monitor S-shaping
correction capacitor and other general purpose usage.
SPECIFICATION:
1.Operating temperature : -40℃ ∼ +85℃
2.Capacitance range : .01μF ∼ 4.7μF
3.Capacitance tolerance : J=±5% , K=±10% , M=±20%
4.Rated voltage (RV) : 100 , 250 , 400 , 630VDC
5.Dissipation factor (DF) : 0.1% max (at 1KHz 25℃)
6.Testing voltage (TV) : 160% of RV for 60sec
7.Insulation resistance (IR) : C≦.33μF,≧100,000MΩ , C＞.33μF,≧33,000MΩ.μF (at 25℃)
(Measured at RV or 500Vdc whichever is smaller , charge time 60s)
 |
