| Type-MPM |
|
|
 THE Type-MPM are constructed with special series metalized
polypropylene film dielectric , tinned copper wire leads and flame retardant epoxy resin coating , in non-inductive type.
FEATURES:
■ Self-healing property.
■ Low DF and inherent temperature rise.
■ High current rating and high dv/dt , High corona starting voltage (C.S.V).
■ High reliability and excellent long term stability.
■ Flame retardant epoxy resin coating (UL-class 94V-0).
APPLICATIONS:
They are ideal for high frequency and high pulse circuits , such as TV or computer monitor horizontal resonance circuits , electric ballast , switching
power supplies, etc.
SPECIFICATION:
1.Operating temperature : -40℃ ∼ +85℃
2.Capacitance range : .001μF ∼ .068μF
3.Capacitance tolerance : J=±5% , K=±10% , M=±20%
4.Rated voltage (RV) : 1000 , 1600 , 2000VDC
5.Dissipation factor (DF) : 0.1% max (at 1KHz 25℃)
6.Testing voltage (TV) : 160% of RV for 60sec.
7.Insulation resistance (IR) : ≧100,000MΩ (at 25℃)
(Measured at RV or 500Vdc whichever is smaller , charge time 60s)
 |
